1. What is the maximum flow rate of steam vortex flowmeter DN50?
TK-WJL vortex flowmeter DN50 has a liquid flow rate of 4-55 cubic meters per hour and a gas flow rate of 35-350 cubic meters per hour.
2. What are the measurement ranges of vortex flowmeters?
1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;
2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;
3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15
1.2-6; DN20
1.5---10； DN25：2---16； DN32
1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130； DN100：18---160； ..... Gas measurement: (unit: m3/h): DN15:4--28; DN20：6---40； DN25：8---50； DN32：15---150； DN40：18---180； DN50：25---480； DN65：50---500； DN80：80---800； DN100：120---1200； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangqiang Automation Technology Co., Ltd.... Www.qszdh. com
3. What is the maximum flow rate of steam vortex flowmeter DN50 with a pressure of 6 kilograms?
The liquid of vortex flowmeter DN50 is modified to 4-55 cubic meters per hour, and the gas is 35-350 cubic meters per hour. 0.6Mpa is approximately 88-951 kilograms of bright debris per cubic meter
4. Parameters
The specifications of Anuba flowmeter include plug-in design from DN50 to DN5000 millimeters, as well as specifications from DN500 to DN5000 millimeters. Its measurement accuracy can reach ± 0.5% and ± 0.2%, with a repeatability of ± 0.1%. In terms of flow range, the range of volumetric flow is 10:
1, 100:1, and the range of mass flow is 8:1. In terms of work pressure, the maximum pressure limit for the uniform speed tube type without a function is 29.00MPa, while the limit for the movable type is 10MPa. The Anuba flowmeter is suitable for fluids with a temperature not exceeding 450 ℃, and the medium viscosity must be below 30CP (equivalent to heavy oil). Sensors and three valve collapse control groups are mainly made of materials such as 316L stainless steel, alloy steel, Hastelloy, and Monel, and flange materials are also available in various options. The working principle of the Annubar flowmeter is based on the Bernoulli equation, which generates high and low pressure areas before and after the probe, and determines the flow rate by measuring the flow velocity difference. Its design features make it suitable for various gas, liquid, and vapor media, with a temperature range from -60 ℃ to 850 ℃ and a pressure range of -1.0 to 42MPa. The flow rate and viscosity need to be calculated based on the actual medium. The advantages of the Anuba flowmeter are significant, including high precision and stability (± 1% and ± 0.1%), reasonable design, easy installation, cost savings, and low pressure loss, which is beneficial for pipeline layout. Although precautions should be taken to prevent blockages in specific situations such as insufficient limb tightness in the straight pipe section after be
