1. Qingdao Aobo ORB-LUGB Vortex Street Steam Flow Meter 80 Size

Qingdao Aobo ORB-LUGB Vortex Street Steam Model World Watch Flow Meter DN80 Specification Parameters and Selection Guide

1. Core Parameters nominal diameter: DN80 (flange mounted) Measuring medium: steam (saturated/superheated), gas, liquid Accuracy level: liquid ± 1.0%, gas/steam ± 1.5% Pressure resistance level: standard 1.6MPa/2.5MPa, customizable 4.0-10.0MPa Temperature range: -20 ℃~350 ℃ (special calibration required for high temperature steam) Body material: 304 stainless steel (contact medium part)

2. Key Features 1 Wide range ratio: usually up to 1:10~1:15, suitable for scenarios with large flow fluctuations No moving parts: using piezoelectric sensors to reduce wear and maintenance requirements Integrated display: On site LCD screen displays instantaneous/cumulative traffic in real-time Signal output: 4-20mA analog signal+pulse output, supporting RS485 communication (MODBUS protocol)

III. Selection precautions • Steam type: saturated steam requires temperature compensation, superheated steam requires temperature and pressure compensation • Installation requirements: front and rear straight pipe sections are recommended to be 20DN/5DN (to ensure measurement accuracy) buried • Protection level: IP65 (outdoor rain and dust protection), explosion-proof type can be selected Ex d Ⅱ CT6

IV. Typical application scenarios • Boiler steam metering (condenser required) • Chemical process steam consumption monitoring • Food processing industry high temperature medium flow control Data source: Qingdao Aobo Instrument 2023 version product technical manual, specific selection needs to be based on actual working conditions paramete

2. What flowmeter is used to measure superheated steam/saturated steam? Vortex flowmeters are generally used to measure superheated steam and saturated steam. To ensure measurement accuracy, appropriate temperature or pressure compensation should be selected based on the characteristics of both. Saturated steam: Water is heated at a certain pressure until it boils and vaporizes. At this point, the steam temperature is equal to the saturation temperature, which is called saturated steam. The saturation pressure and saturation temperature correspond to each other, and both pressure compensation and temperature compensation can be used during measurement. Due to the relatively easy pressure compensation and high measurement accuracy, pressure compensation methods are mostly used in practical applications, such as the use of LUB split vortex flowmeter embedded with HSYB pressure transmitter. Overheated steam: Saturated steam continues to be heated, and when the temperature rises and exceeds the saturation temperature at that pressure, it is called superheated steam. Superheated steam is a single-phase fluid with characteristics similar to gases. Its temperature and pressure are two independent variables, and its density is determined by both. When measuring, any change in temperature or pressure can cause a change in steam density, which in turn affects the mass flow rate. Therefore, temperature and pressure compensation must be performed simultaneously to ensure accuracy, such as when using a LUB split vortex flowmeter with HSYB pressure transmitter and WZPK platinum resistor. In addition, measuring the flow rate of high-temperature steam (superheated steam or saturated steam) can also u
