What flow meter can be used to measure chlorine gas?
The chlorine flowmeter is an intelligent target flowmeter. It is based on the measurement principle of the original strain gauge target flowmeter, and uses the latest capacitive force sensor as the measurement and sensitive transmission intelligent component. At the same time, it utilizes contemporary digital intelligent processing technology to develop a new type of flow measurement instrument.
2. Calculation formula for range adjustment of target flowmeter? The target flowmeter is a new type of flow measurement instrument developed based on the measurement principle of the original strain gauge target flowmeter, using the latest capacitive force sensor as the measuring and sensitive transmission element, and utilizing contemporary digital intelligent processing technology. When the medium flows in the Xiaohuo measuring tube, it generates a pressure difference with the target plate due to its own kinetic energy, resulting in a force on the target plate, causing a slight displacement of the target plate. The magnitude of the force is proportional to the square of the medium flow velocity. The mathematical formula is: F=Cd · A ·ρ· V2/2F: the force acting on the target plate Cd: the fluid resistance coefficient A: the axial projection area of the target plate on the measuring tube ρ: the density of the medium under working conditions V: the characteristic flow velocity of the medium in the measuring tube. The force acting on the chain of the target plate is transmitted through the target rod, causing a slight change in the elastic body of the sensor. After circuit conversion, the corresponding electrical signal is output. Please accept if satisfied!!!
3. Introduction to Target Flowmeters
Target flow meters have been applied in industrial flow measurement since the 1960s, mainly used to solve the flow measurement of high viscosity and low Reynolds number fluids. They have gone through two stages of rapid development: pneumatic meters and electric meters. The SBL series intelligent target flow meter is a new type of flow measurement instrument developed based on the measurement principle of the original strain gauge (capacitive) target flow meter, using the latest force induction sensor as the measurement and sensitive transmission element, and utilizing contemporary digital intelligent processing technology.
.4. How to supply smart gas meters for gas transmission?
The supply of intelligent gas meters adopts a target flowmeter to measure the flow rate of gas transmission by measuring the pressure of the target. The design method of a low-power intelligent IC card natural gas meter based on MSP430 microcontroller. The MSP430 F413 microcontroller is used as the central processor to process the signals collected by the target flowmeter, achieving functions such as gas consumption measurement, total gas consumption accumulation, monthly gas consumption statistics, natural gas fee calculation and management (alarm amount, basic gas consumption, planned gas consumption), and valve control. The remote transmission meter system is more suitable for intelligent gas meters. Intelligent gas meters are equipped with electronic control devices on the basis of membrane gas meters, making them more automated. They entered the market in the late 1990s and achieved large-scale production and application. At present, most of the Zhiying Xianneng gas me
